for diamond tool -Shanghai Knowhow Powder-Tech Co.,Ltd.

Products Description

Powder characteristics

* Produced by chemical method

* Following ISO 9001 standard for quality certification

* The powder manufacturing process is green and pollution-free

* Sold worldwide

* Widely used in powder metallurgy, diamond tools, environmental remediation, electronic components and other industries

Superfine Iron Powder------ZF

characteristic

* Replacing Carbony Iron Powder

* High strength / High hardness

* High performance

Chemical Analysis
Fe			O
≥98.2			≤1.15
Physical Properties
Particle Size Distribution (μm)	D10	1.0-1.5
		D50	2.5-3.5
		D90	4.2-5.2
Apparent Density(g/m³)	1.5-2.5
Theoretical Density (g/m³)	7.86
Sintering Physica Properties
Sintering Temp (°c)	Density (%)	Hardness (HRB)	Bending Strength (MPa)
600	78.58	56.7	365.1
650	95.61	94.5	820.4
700	96.00	95.2	968.9
750	96.69	94.2	1002.0
800	97.36	91.0	943.2
850	95.37	84.1	691.9
900	96.79	82.9	757.7
950	97.17	85.8	750.6

The Best Sintering Range: 700-775℃
The Min.Temperature in Use: 700℃
The Max.Hardness: 97HRB
The Max.Bending Strength: 1176MPa

Superfine Iron Powder------SE-02

characteristic

* For segment, saw blade

* Reduce the content of Cu:30%-15%

*High iron-based formula

Chemical Analysis
Fe			O	N
≥98.5		≤0.85	≤0.66	≤0.01
Physical Properties
Particle Size Distribution (μm)	D10	7.6-8.4
		D50	47.0-48.4
		D90	103.2-104.8
Apparent Density(g/m³)	1.2-1.8
Theoretical Density (g/m³)	7.74
Sintering Physica Properties
Sintering Temp (°c)	Density (%)	Hardness (HRB)	Bending Strength (MPa)
700	91.62	75.6	469.0
750	94.33	86.9	615.8
800	94.33	90.9	702.1
850	98.45	104.6	994.7
900	98.71	108.3	1097.2

The Best Sintering Range: 800-900℃
The Min.Temperature in Use: 820℃
The Max.Hardness: 109.5HRB
The Max.Bending Strength: 1192MPa

Superfine Iron Powder------SE-03

characteristic

* For cold pressed saw blade

* Can reduce the content of Cu

* Good fluidity, cutting material.

Chemical Analysis
Fe			O	N
≥98.4		≤0.70	≤0.70	≤0.01
Physical Properties
Particle Size Distribution (μm)	D10	9.4-10.7
		D50	65.9-66.8
		D90	125.8-126.0
Apparent Density(g/m³)	2.0-2.6
Tap Density (g/m³)	3.1-3.9
Sintering Physica Properties
Sintering Temp (°c)	Density (%)	Hardness (HRB)	Bending Strength (MPa)
700	81.77	41.0	89.2
750	85.94	66.3	236.8
800	92.12	90.6	533.5
850	93.43	100.7	609.6
900	91.85	98.1	608.5

The Best Sintering Range: 800-900℃
The Min.Temperature in Use: 820℃
The Max.Hardness: 103.5HRB
The Max.Bending Strength: 637.1MPa

Superfine Iron Powder------SRB

characteristic

* Wide range of temperature adaption

*Irregular particles can effectively absorb medium-high frequency microwave

* Excellent wave absorption performance within 2-10GHZ frequency

Chemical Analysis
Fe	O	C	N
94.0	≤3.0	≤2.0	≤0.01
Physical Properties
Particle Size Distribution (μm)	D10	1.0-1.5
		D50	2.5-3.5
		D90	4.2-5.2
Apparent Density(g/m³)	1.3-1.8
Tap Density (g/m³)	2.4-3.0
Average Particle Size (mesh)	＞3000
Packing And Storage
Standard Packing (kg/barrel)	25/40			Hardness (HRB)	Bending Strength (MPa)
Packing:	Vacuum and foil bag filled with protective gas sealed and packed in iron drum.			95.5	788.7
Storage:	Store in room tempeerature and dry environment; Avoid high humidity and high temperature; Use immediately after opening the inner bag.			98.0	964.9

Superfine Iron Powder------UHF-P

characteristic

* Replacing Carbony Iron Powder

* High strength / High hardness

* Very high bending strength above 800℃

Chemical Analysis
Fe	O	C	P		Al2O3 , MgO, MnO, CaO, NaO. SiO2
≥96.65	≤1.04	≤0.01	≤2.30		≤0.61
Physical Properties
Particle Size Distribution (μm)	D10	1.0-1.5
		D50	2.2-3.2
		D90	4.0-5.0
Apparent Density(g/m³)	0.9-1.2
Theoretical Density (g/m³)	7.74
Sintering Physical Properties
Sintering Temp (°c)	Density (%)			Hardness (HRB)	Bending Strength (MPa)
700	94.20			97.4	613.8
750	96.70			105.8	886.3
800	96.40			110.2	1206.8
850	96.70			110.6	1422.6
900	97.30			111.7	1445.2

The Best Sintering Range: 800-900℃
The Min.Temperature in Use: 800℃
The Max.Hardness: 112.5HRB
The Max.Bending Strength: 1571MPa
